Design Templates

Proper preparation of the templates guarantees a high quality and successful vinyl pressing service. We are not responsible for any errors made during the formatting or preparation of files for printing. We will not send you hard or soft print proofs before we print the files.

If you follow the instructions and specifications below, you will produce high quality templates. All the information is available on this page or by downloading the files provided. If you have any questions, please contact us personally.

FILE FORMAT

Please send us 300 dpi flattened .PDF files in CMYK (or Pantone) based on our templates only.
We do NOT accept. INDD/.PSD/.AI or any other files.

Save as PDF/X-1a:2001/1.3, exported without scaling or compression.
Other PDF versions may cause transparency issues!

CATALOG NUMBER

Make sure to include the Catalog Number of your project in each file in the following way:
Your Cat. No. – Artwork Type

For example:
GLP001 – Outer Sleeve (or Label/Inner Sleeve etc…)

Please use the same Catalog number as you used for the Info Sheet. You can also find it on your quote or invoice.

TEMPLATES

Always use our templates.
Do NOT use those of other suppliers.
We are not liable for any errors that occur if you do not use them.

Do NOT save the template or any visible cutting, folding and punching lines or color bars in the design you send us. Send us the finished and clean design only.
Fill the cut-out holes of the labels and sleeves with artwork. Please do NOT spare!
Bleed for Labels, Sleeves, Inserts is 5mm extra on all sides. Stickers 2mm, Stamps 0mm.

Vinyl | Center Labels

12″ \| Label \| 100 mm	Download
10″ \| Label \| 100 mm	Download
7″ \| Label \| 92 mm	Download

Vinyl | Gatefold Sleeve

12″ \| Gatefold Sleeve \| 7 mm spine	Download
10″ \| Gatefold Sleeve \| 5 mm spine	Download
7″ \| Gatefold Sleeve \| 5 mm spine	Download

Vinyl | Inner Sleeves

12″ \| Inner Sleeve/Discobag	Download
10″ \| Inner Sleeve/Discobag	Download
7″ \| Inner Sleeve / Discobag	Download

Pay attention! The opening of these templates is standard on the right side, if you want it at the top, adjust your design accordingly.

Vinyl | Outer Sleeves

12″ \| Outer Sleeve \| for 1 Record \| 3 mm Spine	Download
12″ \| Outer Sleeve \| for 2 Records \| 4 mm Spine	Download
12″ \| Outer Sleeve \| for 3 Records \| 7 mm Spine	Download
10″ \| Outer Sleeve \| for 1 Record \| 3 mm Spine	Download
7″ \| Outer Sleeve \| for 1 Record Download	Download
7″ \| Outer Sleeve \| for 2 Records \| 3 mm Spine	Download

Vinyl | Inserts

12″ \| Insert \| 300 x 300 mm	Download
12″ \| Insert \| 600 x 300 mm	Download
10″ \| Insert \| 250 x 250 mm	Download
10″ \| Insert \| 500 x 250 mm	Download
7″ \| Insert \| 175 x 175 mm	Download
7″ \| Insert \| 350 x 175 mm	Download

Vinyl | Tip-On Sleeves

12″ \| Tip-On Sleeve	Download
2″ \| Tip-On Gatefold \|  9 mm spine	Download

Center holes in your Sleeves are optional, if you do not want holes then you can leave them out of your design.
Standard they are 100 mm for 12″ Sleeves and 85 mm for 7″ Sleeves, 92 mm holes are also possible.

Vinyl | Trifold Sleeve

2″ | Trifold Sleeve

Download

Vinyl | Etched Record

12″ | Etched Vinyl Template

Download

Greenlakes Vinyl Mock-Up.
Use royalty free for the promotion of your Record.

OBI strips

12″ \| Vinyl OBI Strip \| Banderole	Download
12″ \| Vinyl OBI Strip \| Fold Over	Download

Vinyl | Mock-Up

12″ | Vinyl Mock Up

Download

Greenlakes Eco-Friendly Vinyl Logo

Eco-Friendly Vinyl logo

Download

Download our Eco-Friendly Vinyl logo to add it to your artwork. This way you can show buyers that the record was pressed at the Greenest Vinyl Pressing Plant in the world.
